Modèle：ADSD32NN02.0
32” ART Smart Display
- Size：32 inch
- System：Android 7.1.2
- WLAN/LAN：WIFI 802.11b/g/n, RJ-45
- Brightness：300 nits
- Resolution：3840 x 2160
- Contrast：1000 : 1
- View Angle：89°/89°/89°/89° (L/R/U/D)
- Color：1.07B (8-bit+Hi_FRC)
- LED Backlight Lifetime：30,000 Hrs.
- I/O Ports：HDMI*2, DP*2, DC IN
| Panel | Model | ADSD32NN02.0 |
|---|---|---|
| Resolution | 3840 x 2160 | |
| Size | 32 inch | |
| Display Area | 708.48 (H) x 398.52 (V) mm | |
| Brightness | 300 nits | |
| Contrast | 1000 : 1 | |
| Viewing Angle | 89°/89°/89°/89° (L/R/U/D) | |
| Response Time | 12 ms | |
| Color | 1.07B (8-bit+Hi_FRC) | |
| Aspect Ratio | 16 : 9 | |
| LED Backlight Lifetime | 30,000 Hrs. | |
| Display Orientation | Landscape / Portrait | |
| Touch Panel | Touch Type | N/A |
| Structure | N/A | |
| Controller IC | N/A | |
| Interface | N/A | |
| Multi-touch | N/A | |
| Transmission Rate | N/A | |
| Surface Hardness | N/A | |
| System | Operating System | Android 7.1.2 |
| CPU | Rockchip RK3288 or RK3399 | |
| RAM | 2GB DDR3 | |
| ROM | 16GB eMMC | |
| Network | AP6212 802.11 b/g/n, 10/100/1000 Mbps | |
| Power | Consumption | < 60 W |
| Input | AC/DC Adapter 100 - 240V, 2A, 50/60Hz | |
| Environment | Operating Temp | 0 ~ 50 ℃ |
| Operating Humidity | 10 ~ 90% RH | |
| Storage Temp | -20 ~ 60 ℃ | |
| Storage Humidity | 20 ~ 80% RH | |
| Dimensions | Panel Cover | Customizable Wooden Frame |
| Net Weight | ~ 10 kg (w/o Wooden Frame) | |
| Body Size | 738.2 (H) x 428.2 (V) x 50.0 (D) mm (w/o Wooden Frame) | |
| Package Box | 113 (H) x 92 (V) x 23 (D) cm | |
| Other | Waterproof | N/A |
| Operation | Brightness, Contrast, Color, H/V Position, etc. | |
| Accessory | Power Cord (~1.5m)*1, AC/DC Adapter DC12V | |
| Speaker | Optional | |
| I/O Ports | DC12V Input, DC12V Out (for Android box) Keypad*1, DP*2, HDMI*2 | |
| Wall Mounting | VESA (200 x 200 mm, 4-M6*10 mm), User Hole 4-ψ10 mm (for Hook) |
